GRINDER ROPPI

Grain crushers are suitable for grinding corn, wheat, oats, barley and other small grain crops. Crushing is carried out between two cylinders (infinitely adjustable depending on the size of grain).

SMK

Water softener with automatical regeneration

Boiling equipment

Doublevessel
V-600 for mini brewery system up to 2 000 HL per year
V-1000 for mini brewery system up to 3 500 HL per year

The most common types:
V-300 for mini brewery system up to 800 HL annually - production capacity 300 L app. 11 hours/600 L app. 22 hour
V-600 for mini brewery system up to 2 000 HL annually - production capacity 600 L app. 11 hours/1 200 L app. 22 hours
V-1000 for mini brewery system up to 3 500 HL annually - production capacity 1 000 L app. 11 hours/2 000 L app. 22 hours
V-1500 for mini brewery system up to 4 500 HL annually - production capacity 1 500 L app. 11 hours/3 000 L app. 22 hours

Examples of boiling equipment - copper:


Steam generator

We offer electric steam generator:

NHV

This tank, equipped with a pumping unit, is designed for storage of preheated water from the first cooling stage and following heating up to 80°C.

Examples of hot water tanks:

CHM

Tabular heat exchanger is two stage equipment.

CKT

Cylindrical vessel with conical bottom part in angle of 60° installed on three adjustable feet, usable capacity from 600 L to 9 000 L.

This vessel is designed for primary and final fermentation of beer.

LTHCHVZ

This vessel is designed for final fermentation, storage and racking of beer.

Examples:

LTVCHV

This vessel is designed for final fermentation, storage and racking of beer.
This cylindrical vessel is installed on three adjustable feet, with efficient capacity of 600 L up to 6 000

Examples:

PTVCHD

This vessel is designed for final fermentation, storage and racking of beer.
This cylindrical vessel is installed on three adjustable feet, with efficient capacity of 600 L up to 9 000 L.

Examples:

VLV

Assigned above all for cooling of machine tools lubricating oil. Cooling and constant temperature maintenance frames for machine tools optimal work conditions. This conduce to continuously maximum rating of machining.

Examples:

VCHV

Examples:

ZLV

This ice water tank is designed for accumulation of cold in water and its following utilisation for beer cooling in the second cooling stage and for further cooling of particular vessels and tanks in breweries. This tank is coupled with 2 pumps with capacity of 95 l/min for closed primary and secondary circuits.
The tank itself is mounted on 6 adjustable feet and closed with a stainless cover.

Examples:

RGK

This tank, designed for recovery, storage and cleaning of brewery yeasts, hereinafter referred to as RGK, is made of stainless steel 1.4301. The RGK cylindrical part is covered with duplex jacketing for tank cooling, clearance of 12 mm. The tank should be simply connected to the ice water distribution network with hoses. Its top part is provided with a manhole for checking and sanitation. RGK is bedded in framing on two pins that enable its inclination by 130° in both directions. RGK is designed for overpressure and its design enables inside yeasts dosing even without pumps.

Two types:

CIP

This equipment CIP is designed for sanitation and sterilisation of vessels. Its function is based on circulation of an alkaline or acid solution through a sanitary shower spraying it onto vessel walls and into its space. It is equipped also with a flow heater with digital regulation of temperatures ranging from 0°C to 80°C.

The equipment CIP is installed in a rigid a frame provided with lockable travel wheels. Used material is stainless steel 1.4301.

Two basic types:

KSV

Three main types:

Additional Components

Drift filters FKS
Washing and Filling Machine Sankeg 25, Sankeg 10
Beer parlor 1T4
Beer parlor 2T6
